Portable. Deployable. Proven.
IF800 TOMCAT
A mission-ready quadcopter built for professional field operations.
.png){kind=small}
.png){kind=small}
.png){kind=small}
IF800 equipped with the Sentera RTK/PPK module and 65R high resolution RGB camera during a precision mapping mission.
Image Details
MISSION-READY PERFORMANCE
54MIN
MAX FLIGHT TIME
49MPH
MAX SPEED
6.6LBS
MAX PAYLOAD CAPACITY
MULTIPLE PAYLOAD TYPES
One aircraft. Multiple missions. The IF800 integrates with a wide range of industry-leading sensors, allowing teams to adapt quickly as project requirements change.
JD D’Arville, Alabama DOT
“Based on what we saw on this project, we plan to use the IF800 and 65R payload for pavement work every time we fly an airport.”
CASE STUDIES
PROVEN IN THE FIELD
Deployed daily across survey, inspection, and infrastructure missions nationwide.
Two Options Available
CHOOSE YOUR GROUND CONTROL STATION
Configuration options matched to your workflow.
AIRCRAFT SPECS
Engineered for real-world use. Built to meet the demands of professional operators across survey, inspection, and research applications.
Specification | Metric Value | Imperial Value |
|---|---|---|
Max Ascent Speed | 5m/s | 16 ft/s |
Max Descent Speed | 3m/s | 10 ft/s |
Max Air Speed | 22m/s | 49 mph |
Max Wind Resistance | 10m/s, 12m/s gusts | 19 knot, 23 knot gusts |
Max Tilt Angle | 60° | |
Max Angular Velocity | Tilt: 300%, Yaw: 120% | |
Operating Temperature | -20°C ~45°C | -4°F ~113°F |
Ingress Protection | IP43, 5%~99% Humidity | |
Service Ceiling (with given payload) | 4.2km (14,000 ft) w/0.0 kg, | |
3.2 km (10,500 ft) w/ 1.5 kg, | ||
2.0 k m (6,500 ft) w / 3.0 kg |
